Breather valves play a crucial role in industrial storage tanks and engine systems. They not only balance internal and external pressures but also prevent excessive evaporation and structural damage. Whether in fuel tank breather valves, tank breather valves, or engine applications, regular inspection and maintenance extend equipment life and ensure safe operation. This article explains in detail how to check a breather valve and provides a complete, practical guide, leveraging the advantages of Zhen Chao breather valves.
A breather valve, sometimes called a Pressure Vacuum Relief Valve, is designed to regulate pressure in enclosed spaces. It serves two main purposes:
Isolation within pressure limits: The valve ensures that the tank space is isolated from the atmosphere within a specific pressure range.
Pressure relief beyond limits: When pressure exceeds or falls below the set range, the valve communicates with the atmosphere to relieve pressure.
Begin by inspecting the valve and connected pipes for obvious issues:
Look for cracks, chafing, or wear in rubber, PVC, or metal pipes
Inspect for oil, dirt, or debris buildup inside the valve
Ensure all clips, fasteners, and seals are secure
Damaged or dirty components can prevent proper airflow, leading to valve malfunction. Replace any defective parts before proceeding to testing.
To perform a breather valve test:
Disconnect the valve from the tank, engine, or system according to manufacturer guidelines.
Attach a clean rubber or plastic pipe to the larger end of the valve (e.g., rocker/cam or crankcase end for engine breather valves).
Blow through the pipe: Air should pass through easily.
If airflow is blocked, the valve may be clogged, or the spring inside is broken.
Reconnect the pipe to the inlet-manifold or tank end and blow through again:
Only limited airflow should pass with difficulty.
If air flows freely, the valve may be jammed or worn and should be replaced.
For industrial tanks, a hand pump or low-pressure air source can simulate tank pressure to test the Pressure Vacuum Relief Valve.
Cleaning is essential to maintain airflow and valve longevity:
Remove the valve carefully from the system.
Immerse it in paraffin or a suitable cleaning solvent to loosen oil and dirt deposits.
Take precautions against fire hazards; do not smoke nearby.
Flush short pipes with paraffin and blow dry with a foot pump.
Inspect pipes for cracks, chafing, or blockages. Replace damaged pipes.
Reassemble the valve and reconnect all pipes, ensuring tight and clean connections.
Regular cleaning can prevent fuel tank breather valve symptoms like clogging, vapor lock, or uneven fuel flow.
For industrial applications, it is essential to ensure the valve is sized correctly:
Calculate the maximum and minimum allowable pressures for the tank or system
Verify that the breather valve’s specifications match the required pressure ranges
Confirm that the valve can handle expected evaporation losses and pressure fluctuations
Accurate breather valve calculation ensures safe operation and reduces the risk of tank overpressure or vacuum damage.
Fuel tank valves control vapor pressure and prevent fuel evaporation:
Disconnect the valve and attach a testing pipe
Blow air through the tank side; airflow should be restricted
Blow air through the vent side; airflow should pass easily
Inspect for fuel tank breather valve symptoms such as spillage, difficulty refueling, or strong vapor odors
Replace or clean if airflow is blocked or inconsistent
Zhen Chao breather valve ensures precise fuel vapor control for safer, more efficient fuel tanks.
Engine breather valves are part of the Positive Crankcase Ventilation (PCV) system:
Disconnect emission-system pipes and inspect for dirt, oil, or cracks
Use a foot pump to blow through pipes and remove debris
Check airflow through the valve:
Correct operation: Easy flow from crankcase side, restricted flow from manifold side
Malfunction: Blocked airflow or free flow where restriction is expected
Clean the valve by immersion and reassemble according to the engine manual
Properly functioning engine breather valves prevent excessive crankcase pressure, protecting engine components and improving performance.
Industrial tanks often use Pressure Vacuum Relief Valves:
Simulate pressure and vacuum using a hand pump
Ensure the valve opens and closes at the set pressure ranges
Inspect for dirt or corrosion inside the valve and clean as needed
Verify that venting capacity matches tank size and evaporation loss requirements
Regular inspection and testing prevent structural damage, product loss, and safety hazards.
Knowing how to check a breather valve? It is essential for maintaining fuel tanks, water tanks, engines, and industrial storage systems. By performing visual inspections, operational tests, cleaning, and calculations, you can ensure your system operates safely and efficiently. High-quality valves, like Zhen Chao breather valve, offer reliable pressure control, long-term durability, and easy maintenance. Protect your tanks and engines today—choose Zhen Chao for superior breather valves. Test and maintain your valves regularly to prevent overpressure, vacuum damage, and evaporation loss. Ensure safety and efficiency with Zhen Chao breather valve solutions you can trust.
