The ZCGLY-II Gauge Hatch With Lock is a premium, secure sampling access point for atmospheric storage tanks. This specialized gauge hatch provides an airtight seal for manual level measurement and oil sampling while preventing unauthorized access through its integrated locking system. Its rotating, spark-proof design makes it an industry standard for hazardous oil and chemical storage.
Producdt Description：
The ZCGLY-II Gauge Hatch With Lock is a premium safety and sampling access point designed for atmospheric and low-pressure storage tanks. This specialized gauge hatch provides a secure, airtight seal for manual level measurement, temperature sensing, and oil sampling while preventing unauthorized access via its integrated locking system. Engineered for hazardous environments, its rotating design and spark-proof capabilities make it an industry standard for oil, gas, and chemical storage.
Operating pressure:
Note:
Under normal circumstances, (fire) breathing valve operating pressure to B shall prevail;
Applicable materials: gasoline, kerosene, diesel, aromatics, sulfur, air and other petrochemical materials;
Environment temperature: -40 °C -+60 °C;
Shell material: HT, AL, A3, 18-8, 304, 304L, 316, 316L.
Flange standards: HG20592-97 PN1.0 (also can be produced according to user specified criteria)
“Unsure about material compatibility? Speak with our safety engineers today.”
Q1: What is the primary advantage of the ZCGLY-II over standard gauge hatches?
A1: The ZCGLY-II features an integrated locking mechanism and a rotating cover. This combination provides superior security against unauthorized access while allowing for easy operation in tight spaces.
Q2: Can the ZCGLY-II Gauge Hatch be used in explosive environments? A2: Yes. For hazardous zones, we provide spark-proof options using copper sealing rings or specialized anti-static gaskets to prevent frictional ignition during use.
Q3: What materials are available for the hatch body?
A3: We offer the ZCGLY-II in Carbon Steel, SS304, and SS316. Stainless steel options are highly recommended for chemical storage or coastal environments where corrosion is a concern.
Q4: Does the lock require special tools to operate?
A4: The hatch is designed for manual operation; the locking eyebolt and wing nut can be tightened by hand, and a standard padlock can be applied to the designated locking point for full security.
Q5: What flange standards are compatible with this gauge hatch?
A5: Our gauge hatches are highly customizable and can be manufactured to meet ANSI, DIN, JIS, or GB flange standards to ensure a perfect fit with your existing tank nozzles.
